Practical answers for planning, specifying, installing and operating transparent silicon-based LED glass.

Support

Clear answers before your project begins.

Explore the technology, selection, installation and support questions most often raised during transparent LED glass planning.

01

Understanding the technology

What is transparent silicon-based LED glass?

ClearSignal LED glass combines architectural glass with integrated transparent display technology. Digital content appears directly on the glass while natural light, visibility and the architectural character of the space are preserved.

How is LED glass different from a conventional LED wall?

A conventional LED wall creates an opaque visual surface. Transparent LED glass remains part of the architecture, allowing people to experience the displayed content and the environment behind it at the same time.

What does the glass look like when the display is switched off?

When switched off, the glass remains transparent and continues functioning as an architectural surface. Display components may remain subtly visible at close range depending on pixel pitch and configuration.

How transparent is ClearSignal LED glass?

Transparency depends on pixel pitch, product family, dimensions and installation design. Selected configurations can provide transparency of up to 95%. The final value is confirmed during technical specification.

Can the display remain visible during daylight?

Yes, when the correct brightness and pixel configuration are selected. Building orientation, direct sunlight, viewing distance and surrounding light conditions are evaluated before a solution is recommended.

02

Selecting a solution

How do I choose the right pixel pitch?

Pixel pitch is selected according to viewing distance, required image detail, transparency, display dimensions and content type. A finer pitch provides greater detail, while a wider pitch can improve transparency and viewing performance from longer distances.

Which ClearSignal product should I choose?

ClearSignal offers Curtain Wall Display, Guardrail Display and Commercial Showcase Display solutions. Window-screen and mobile showcase installations are included within the Commercial Showcase Display family. We recommend the final configuration after reviewing the site and communication goal.

Where can transparent LED glass be used?

Applications include retail storefronts, shopping centres, building façades, corporate spaces, airports, transportation hubs, museums, exhibitions, stadiums, hospitality environments, guardrails and commercial showcases.

Can the glass be customized?

Yes. Dimensions, pixel pitch, brightness, transparency, display layout and control systems can be engineered around the project. Curved or irregular applications require an individual technical review.

Can it be installed outdoors?

Selected configurations can be designed for exterior and demanding environments. Weather resistance, IP rating, temperature range, structural loading and local compliance requirements are confirmed for each project.

03

Installation and operation

Can ClearSignal LED glass replace existing glass?

This depends on the building and selected product. Some systems are integrated into new glazing, while others may be adapted to existing architectural conditions. A site and structural assessment is required before confirmation.

What is the ClearSignal project process?

The typical process includes discovery, site assessment, solution design, technical confirmation, content planning, production, testing, logistics, installation, commissioning, training and after-sales support.

Does the system require additional cooling?

The technology is designed to manage heat efficiently through its glass construction, and specified configurations may operate without separate external cooling. Final thermal and electrical requirements are confirmed during engineering.

How is content uploaded and controlled?

Content can be managed through the control system selected for the project. Local playback, scheduled programming and remote content management can be provided depending on network and security requirements.

What content works best on transparent LED glass?

Bold typography, high-contrast graphics, motion content and compositions with dark or transparent backgrounds generally produce the strongest results while retaining visibility through the glass.

04

Maintenance and commercial

What maintenance is required?

Maintenance generally includes appropriate glass cleaning, system inspections, software updates and checking electrical and control components. ClearSignal provides project-specific care instructions and can recommend spare parts when necessary.

What is the expected operating life and warranty?

The current technology-partner framework provides an operating-life reference of up to 50,000 hours and a warranty framework of up to three years. Binding terms and operating conditions are stated in the final ClearSignal quotation and contract.

How much does transparent LED glass cost?

Every project is quotation-based. Cost is influenced by display dimensions, glass construction, pixel pitch, brightness, control system, supporting structure, logistics, installation and local compliance requirements.

How long does a project take?

The timeline depends on engineering complexity, approvals, custom production, testing, transportation and installation. ClearSignal provides a project schedule after the design and technical requirements are approved.

What is the relationship between ClearSignal and JIGGROW?

ClearSignal is the customer-facing brand responsible for solution development and project coordination. JIGGROW supports ClearSignal as a specialist technology and manufacturing partner. Certain factory, testing and technical videos may therefore display the JIGGROW identity.
